AUDIO-GD D77 DEDICATED DISCRETE FULLY BALANCED DAC

AUD677_0,0(0),0,0
https://neutrinomobile.hr/web/image/product.template/1867/image_1920?unique=7530d45
Potrebna provjera kod dobavljača
  • BRAND
  • Tag jamstvo

1.194,37 € 1.194,37 € 1194.3700000000001 EUR Jednokratno

Gotovina, pouzeće, virman, Visa, Master, Maestro jednokratno

 1.257,23 € 1.257,23 € Na rate

Jednokratno Diners, sve kartice na rate

1.194,37 €

Uključuje 25% PDV-a

This combination does not exist.

Dodaj u košaricu
Besplatna dostava
Jamstvo 24 mjeseci

Built In FPGA Processor to Reject Jitter, Dual Sabre ES9038Pro, 32bit / PCM384K /DSD512 asynchronous transfer, Amanero 384 apply the FPGA synchronous clock, HDMI & USB support up to DSD512, Built with OCC and Hi-end parts

Dodatne specifikacije za AUDIO-GD D77 DEDICATED DISCRETE FULLY BALANCED DAC

S/N Ratio
>120DB  (XLR output)
　

THD
　		 <0.0003%

Output impedance
　		 4.7 ohm

Output Level
　		 2.5V (RCA)
5V (XLR)
2+2MA (ACSS)
Input Sensitivity
0.5 Vp-p(75 Ohms, Coaxial)
19 dBm (Optical)
　
Frequency Response
20Hz - 20KHz (< - 0.1DB)
　

Support Operate Systems (USB)
　


Windows , OSX ,Linux, ISO
　
Support Sampling
 PCM of USB and I2S: 44.1kHz-84kHz
DSD of USB and I2S: DSD64-512
 Coaxial model: 44.1kHz-192kHz
Optical model: 44.1kHz-96kHz
　
Power Requirement
 Version 1: 100-130V  AC 50/60 Hz
Version 2:  220-240V  AC 50/60 Hz
　
Power Consumption
30W
　
Package Weight
Approximately 5.5KG
　

Dimensions
　		 W240 X L360 X H80 (MM, Fully aluminium )
Accessories
AC power cord            X1
USB cable                X1

Specifikacija za AUDIO-GD D77 DEDICATED DISCRETE FULLY BALANCED DAC
