FX-AUDIO DAC-M1 DAC ES9038Q2M XMOS 32BIT 768KHZ DS512 BLUETOOTH 5.0 GRAY
AUD1687_0,0(0),0,0
Potrebna provjera kod dobavljača
Besplatna dostava
Jamstvo 24 mjeseci
FX-Audio DAC-M1 je kompaktan, pristupačan i snažan digitalno-analogni pretvarač. Temelji se na korištenju ESS ES9038Q2M DAC čipa, povezanog s XMOS XU208 USB sučeljem, omogućavajući podršku za audio streamove visoke razlučivosti, do PCM 32bit 768kHz i DSD512, dok nudi izvrsnu transparentnost zvuka.
Dodatne specifikacije za FX-AUDIO DAC-M1 DAC ES9038Q2M XMOS 32BIT 768KHZ DS512 BLUETOOTH 5.0 GRAY
Technical characteristics
| SPECIFICATIONS | |
|---|---|
| Product type | DAC |
| DAC Chip | ES9038Q2M |
| USB Interface | XMOS XU208 |
| Headphone amplifier chip | TPA6120A2 |
| Bluetooth reception chip | CSR8675 |
| Inputs | 1x USB-C 1x Optical Toslink 1x Coaxial Bluetooth 5.0 |
| Outputs | 1x Stereo RCA 1x Jack 6.35mm headphone output |
| THD+N | 0.00025% |
| SNR | 118dB |
| USB Transmission mode | Asynchronous |
| USB Compatibility | Windows 7 / 8 / 8.1 / 10 Mac OSX 10.6 Linux |
| Supported sampling rates | USB : PCM up to 32bit 768kHz, Native DSD up to DSD512 Optical / Coaxial : PCM up to 24bit 192kHz, DSD DoP up to DSD64 Bluetooth : PCM up to 24bit 96kHz |
| Headphone output power | 500mW @ 32Ω 340mW @ 64Ω 180mW @ 150Ω 96mW @ 300Ω |
| GENERAL | |
|---|---|
| Consumption | 3.5W |
| Standby consumption | 0.25W |
| Dimensions | 130 x 10 x 55mm |
| Weight | 350g |
| Color | Gray |
| Package | 1x FX-Audio DAC-M1 1x Power adapter 12V 1A 1x Bluetooth antenna 1x Remote control |
